5mm Round Lamp

Datasheet 3D Step File

Information Inquiry:



INL-5AX30

5mm Round Lamp Super Bright 8.65mm Lens

Product λD(nm) Current (mA) IV (mcd) VA 2θ1/2 Vf (V) Emission Color Lens Color
typ max
INL-5AYG30 573 20 460 30 2.6 Yellow Green W.C.
INL-5AY30 590 20 1000 30 2.6 Yellow W.C.
INL-5AA30 605 20 780 30 2.6 Amber W.C.
INL-5AR30 624 20 1300 30 2.6 Red W.C.
INL-5AB30 470 20 5000 30 3.8 Blue W.C.
INL-5AG30 525 20 23000 30 3.6 Green W.C.
INL-5AW30 x=0.28 Y=0.28 20 8500 30 3.8 White W.C.
