| Product | Color | λ (nm) | IF (mA) | IV (mcd) | VA 2θ1/2 | VF (V) | Lens Color |
|---|---|---|---|---|---|---|---|
| max | |||||||
| INP-5A4RGB50 | Red | 624 | 20 | 1000 | 50 | 2.4 | W.C. |
| Green | 525 | 20 | 2000 | 50 | 3.6 | W.C. | |
| Blue | 470 | 20 | 500 | 50 | 3.6 | W.C. |
